HP Series 5 Pro 14 inch WQXGA Portable Monitor - 514pn
- Carry true portable dual-screen productivity anywhere with this portable 14” display delivering WQXGA resolution and a 16:10 aspect ratio to match your notebook.
- Bring content to life wherever you are with IPS Black with Neo:LED panel technology, delivering striking color, brightness, and clarity.[2]
- Exercise versatility with an ultra-thin portable monitor with built-in stand that adapts to landscape or portrait, protected by a magnetic hard screen cover.
- Thoughtfully designed with at least 90% recycled plastic content in the monitor's enclosure, 20% recycled glass in the monitor panel, and 55% recycled aluminum.[3]
| SKU | B88JWAA#ABB |
|---|---|
| EAN | 0198990467757 |
| Manufacturer | HP |
| Availability | N |
| Product Family | Series 5 Pro |
| Product Videos |
View Video |
Seamless Color Consistency Without Compromise
IPS Black with Neo:LED panel technology offers wide color coverage with 100% Adobe RGB, and 100% Display P3.[2]
Stay Connected with a Single Cable
Free up space and stay agile with a single L-shaped USB-C cable that can connect to either of two USB-C ports and handle up to 65W of power delivery.[1]
Thin, Light Design with Hard Cover Protection
Easily bring your work setup anywhere with a thin, lightweight portable monitor protected with a durable magnetic hard screen cover that doubles as a mousepad.
A Versatile Stand that Supports Flexibility
Choose the angle that best supports your workflow with a versatile mode and adjustable kickstand. Easily pivot or use in landscape.
Improved Visual Comfort
Protect your eyes with a monitor that meets the TUV Rheinland Eye Comfort 3.0 - 3 star criteria with HP Eye Ease low blue light filter, 75 Hz refresh rate, wide color coverage and flicker free.[2,5]
HP Display Center
Customize your monitor with the intuitive HP Display Center that lets you tailor your settings, partition screens, and more—all through the host PC.[6]
Remote Management Reimagined
The powerful HP Client Management Script Library (CMSL) works seamlessly with Intune/SCCM to make managing your fleet remotely easy using PowerShell.[7]
Made with Materials that Matter
Designed with at least 90% recycled plastic content in the enclosure, 20% recycled glass in the monitor panel, and 55% recycled aluminum.[3]
Thoughtful Product Packaging
100% of the paper-based packaging is sustainably sourced or recycled.[4]
Increased Energy Efficiency
To help protect our shared future, this monitor is held to the highest energy saving standard with an ENERGY STAR rating and EPEAT® Gold Registration.[8]
Works on Mac® or PC
Verified with devices running across OS, this monitor works with Mac® or PC devices.[9]
Portable dual-screen productivity powered by one cable
Carry your office space everywhere. See more and do more on the go with a 14” WQXGA 16:10 display that connects to your notebook via a single USB-C cable delivering up to 65W[1] of power for dual-screen productivity anywhere.
Thin, light, and versatile enough to take wherever work takes you
Exercise versatility in any space with an ultra-thin, lightweight portable monitor you can easily add to your bag with a durable magnetic hard screen cover that doubles as a mousepad. The built-in kick-stand adapts to landscape or portrait to fit your workflow.
Take your dual screen setup anywhere and stay productive on the go without sacrificing picture quality with the HP Series 5 Pro 14” Portable Monitor. Breakthrough Neo:LED delivers stunning visuals in a feather-light frame to fit any space, making it the perfect sidekick for your notebook.
| Display | |
|---|---|
| HDCP | Yes |
| Display brightness (typical) | 400 cd/m² |
| Screen shape | Flat |
| Display number of colours | 16.7 million colours |
| Native aspect ratio | 16:10 |
| Pixel density | 216 ppi |
| Colour gamut | 100% |
| Maximum refresh rate | 75 Hz |
| sRGB coverage (typical) | 100% |
| Display surface | Matt |
| HD type | WQXGA |
| Display technology | LCD |
| Contrast ratio (dynamic) | 10000000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.1178 x 0.1178 mm |
| Horizontal scan range | 31 - 124 kHz |
| Vertical scan range | 50 - 75 Hz |
| Aspect ratio | 16:10 |
| Viewable size, horizontal | 30.1 cm |
| Viewable size, vertical | 18.8 cm |
| Supported graphics resolutions | 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA), 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA) |
| Backlight type | Edge LED |
| Display resolution | 2560 x 1600 pixels |
| Response time | 7 ms |
| Display diagonal | 35.6 cm (14") |
| Contrast ratio (typical) | 2000:1 |
| Surface hardness | 3H |
| Touchscreen | No |
| Display bezel technology | Narrow Border |
| Panel type | IPS Black |
| Colour depth | 8 bit |
| Display diagonal (metric) | 35.6 cm |
| Haze rate | 25% |
| LED backlight | Yes |
| Display brightness | 400 cd/m² |
| Colour gamut standard | sRGB |
| Response time measurement type | GTG (Gray to Gray) |
| Anti-glare screen | Yes |
| Audio | |
| Built-in speaker(s) | No |
| Performance | |
| Built-in speaker(s) | No |
| Built-in camera | No |
| AMD FreeSync | No |
| NVIDIA G-SYNC | No |
| HP segment | Business |
| Low Blue Light technology | Yes |
| Flicker-free technology | Yes |
| Fast charging | Yes |
| Management features | |
| On Screen Display (OSD) | Yes |
| Multimedia | |
| Built-in speaker(s) | No |
| Built-in camera | No |
| Design | |
| Market positioning | Business |
| Country of origin | China, Vietnam |
| Feet colour | Silver |
| Certification | BIS; BSMI; CB; CCC; CE; cTUVus; EAC; FCC; ISO 9241-307; KC; KCC; NOM; TUV/GS; VCCI; Vietnam MEPS; WEEE; ISC; ICE; UAE; NRCS |
| Product colour | Silver |
| Colour name | Silver |
| Camera | |
| Built-in camera | No |
| Ports & interfaces | |
| USB Type-C downstream ports quantity | 2 |
| Headphone out | No |
| HDCP | Yes |
| HDMI | No |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 65 W |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Technical details | |
| Feet colour | Silver |
| Cable lock slot | No |
| HDMI | No |
| Product colour | Silver |
| UNSPSC-code | 43211902 |
| Sustainability certificates | ENERGY STAR, EPEAT |
| Box contents | Monitor; Warranty card; Quick Setup Poster; 1 USB Type-C to Type-C cable; Hard screen cover |
| Compliance certificates | CCC, CB, EAC, BIS, Federal Communications Commission (FCC), CE, BSMI |
| General Product Safety Regulation (GPSR) URL | https://support.hp.com/us-en/document/ish_6126692-6126777-16?openCLC=true |
| HP GTIN (EAN/UPC) | 198990467832 |
| Country of origin | China, Vietnam |
| Power supply type | External |
| Weight (with stand) | 630 g |
| Surface hardness | 3H |
| Touchscreen | No |
| Software | |
| Bundled software | HP Display Center; HP Client Management Script Library |
| Ergonomics | |
| VESA mounting | No |
| Cable lock slot | No |
| Tilt angle range | 18.8 - 46.2° |
| On Screen Display (OSD) | Yes |
| Height adjustment | No |
| Tilt adjustment | Yes |
| Power | |
|---|---|
| Power supply type | External |
| Power consumption (max) | 13 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 7 W |
| Power consumption (off) | 0.3 W |
| Energy efficiency scale | A to G |
| Energy efficiency class (SDR) | B |
| Energy efficiency class (HDR) | B |
| Energy consumption (SDR) per 1000 hours | 5.6 kWh |
| Operational conditions | |
| Non-operating altitude | 0 - 12192 m |
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 20 - 80% |
| Operating altitude | 0 - 5000 m |
| Weight & dimensions | |
| Width (with stand) | 320.6 mm |
| Depth (with stand) | 8.8 mm |
| Height (with stand) | 208.6 mm |
| Weight (with stand) | 630 g |
| Package width | 398 mm |
| Package depth | 60 mm |
| Package height | 278 mm |
| Package weight | 1.27 kg |
| Weight | 630 g |
| Packaging data | |
| Package width | 398 mm |
| Package depth | 60 mm |
| Package height | 278 mm |
| Package weight | 1.27 kg |
| Package type | Box |
| Warranty card | Yes |
| Stand included | Yes |
| Quick start guide | Yes |
| Cables included | USB Type-C to USB Type-C |
| Bundled software | HP Display Center; HP Client Management Script Library |
| Packaging content | |
| Stand included | Yes |
| Quick start guide | Yes |
| Cables included | USB Type-C to USB Type-C |
| Bundled software | HP Display Center; HP Client Management Script Library |
| Sustainability | |
| Total carbon footprint (kg of CO2e) | 200 |
| Sustainability certificates | ENERGY STAR, EPEAT |
| Carbon footprint | |
| Total carbon footprint (kg of CO2e) | 200 |
| Total carbon emissions, w/o use phase (kg of CO2e) | 36 |
| Carbon emissions, manufacturing (kg of CO2e) | 156 |
| Carbon emissions, logistics (kg of CO2e) | 3 |
| Carbon emissions, end-of-life (kg of CO2e) | 2 |
| Features | |
| Country of origin | China, Vietnam |
| Other features | |
| Country of origin | China, Vietnam |
| Certification | BIS; BSMI; CB; CCC; CE; cTUVus; EAC; FCC; ISO 9241-307; KC; KCC; NOM; TUV/GS; VCCI; Vietnam MEPS; WEEE; ISC; ICE; UAE; NRCS |
| UNSPSC-code | 43211902 |
| Weight | 630 g |
| Compliance certificates | CCC, CB, EAC, BIS, Federal Communications Commission (FCC), CE, BSMI |
| Manufacturer warranty | HP three-year limited warranty |
| Power consumption (max) | 13 W |
| Quick start guide | Yes |
| HDMI | No |
| Surface hardness | 3H |
| USB Power Delivery up to | 65 W |
| Energy efficiency scale | A to G |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Power supply type | External |
| Touchscreen | No |
| USB Power Delivery (USB PD) | Yes |
| Package type | Box |
| Logistics data | |
| Total carbon footprint (kg of CO2e) | 200 |
| Brand-specific features | |
| HP GTIN (EAN/UPC) | 198990467832 |
| Certificates | |
| Certification | BIS; BSMI; CB; CCC; CE; cTUVus; EAC; FCC; ISO 9241-307; KC; KCC; NOM; TUV/GS; VCCI; Vietnam MEPS; WEEE; ISC; ICE; UAE; NRCS |
